Camp 4: Monitoring & Telemetry

Reaching Observation Peak

Monitoring

Camp Details

Tech Stack: Log Analytics, Application Insights, Azure Monitor, Workbooks, API Management, Container Apps, Functions, MCP
Primary Risks: MCP08 (Lack of Audit and Telemetry)

Welcome to Observation Peak!

You've made it to Camp 4, the last skill-building camp before the Summit! Throughout your journey, you've built authentication (Camp 1), MCP gateways (Camp 2), and I/O security (Camp 3). Your MCP server is now protected by multiple layers of defense.

But here's a question: How do you know it's working?

If an attacker probed your system last night, would you know? If your security function blocked 100 injection attempts yesterday, could you prove it to an auditor? If there's a sudden spike in attacks right now, would you be alerted?

This is where observability comes in, and it's just as important as the security controls themselves.

The Key Insight

Security controls without observability are like locks without security cameras. You might stop the intruder, but you'll never know they tried to get in.

What You'll Learn

At Observation Peak, you'll learn to see everything happening across your MCP infrastructure:

Learning Objectives

  • Enable APIM diagnostic settings for gateway and AI gateway logs
  • Implement structured security logging in Azure Functions with correlation IDs
  • Query logs using KQL for security investigations with full log correlation
  • Build security monitoring dashboards using Azure Workbooks
  • Create alert rules for attack pattern detection
  • Perform incident response exercises with cross-service log tracing

Understanding Observability

Before diving into the hands-on work, let's understand why observability matters and what makes it different from basic logging.

Logging vs. Observability

You might be thinking: "I already have logs. My application writes to console. Isn't that enough?"

Not quite. There's a crucial difference:

Aspect Basic Logging Observability
What it captures Text messages Structured events with dimensions
How you search Grep through files Query across services in seconds
Correlation Manual, painful Automatic via correlation IDs
Visualization Read log files Dashboards, charts, trends
Alerting Custom scripts Built-in threshold monitoring

A Tale of Two Approaches

Basic logging: WARNING: Injection blocked: sql_injection

  • Where did it come from? 🤷
  • What tool was targeted? 🤷
  • How many happened today? 🤷 (time to write a grep script...)

Structured observability:

{
  "event_type": "INJECTION_BLOCKED",
  "injection_type": "sql_injection",
  "tool_name": "search-trails",
  "correlation_id": "abc-123-xyz",
  "caller_ip": "203.0.113.42",
  "timestamp": "2024-01-15T14:30:00Z"
}

Now you can instantly answer: "Show me all SQL injections targeting the search-trails tool in the last hour, grouped by source IP."

The Three Pillars of Observability

Modern observability rests on three pillars:

  • Logs

    Discrete events that tell you what happened. "User called tool X" or "Injection blocked."

  • Metrics

    Numerical measurements over time. Requests per second, error rates, latency percentiles.

  • Traces

    The path a request takes through your system. Essential for understanding "why was this slow?"

In this workshop, we focus primarily on logs (structured events) while touching on metrics and traces through correlation IDs.

The Real-World Problem

Imagine this scenario: You're the security lead for a company using MCP servers. Your manager walks over and asks:

"We had a security audit last week. The auditor wants to know how many attacks we've blocked in the past 30 days. Can you pull that report?"

Without proper monitoring, your answer might be: "I'd have to grep through thousands of log files..."

With structured telemetry, your answer is: "Give me 30 seconds."

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| where tostring(CustomDims.event_type) == "INJECTION_BLOCKED"
| where TimeGenerated > ago(30d)
| summarize AttacksBlocked = count() by bin(TimeGenerated, 1d)
| render barchart

That's the power of observability.

Meet Azure Monitor

Before we start configuring things, let's understand the Azure services we'll be working with. Think of Azure Monitor as your observability platform, it's actually a collection of services working together.

The Azure Monitor Family

┌─────────────────────────────────────────────────────────────────────┐
│                         Azure Monitor                               │
│  ┌─────────────────┐  ┌─────────────────┐  ┌─────────────────────┐  │
│  │  Log Analytics  │  │   Application   │  │    Azure Monitor    │  │
│  │    Workspace    │  │    Insights     │  │      Alerts         │  │
│  │                 │  │                 │  │                     │  │
│  │  • Store logs   │  │  • Auto-collect │  │  • Threshold rules  │  │
│  │  • KQL queries  │  │    from apps    │  │  • Email/webhook    │  │
│  │  • Retention    │  │  • APM features │  │  • Action groups    │  │
│  └────────┬────────┘  └────────┬────────┘  └──────────┬──────────┘  │
│           │                    │                      │             │
│           └──────────────┬─────┴──────────────────────┘             │
│                          │                                          │
│              ┌───────────┴───────────┐                              │
│              │    Azure Workbooks    │                              │
│              │   (Visualizations)    │                              │
│              └───────────────────────┘                              │
└─────────────────────────────────────────────────────────────────────┘

Log Analytics Workspace is your central log repository. Think of it as a powerful database optimized for time-series log data. You query it using KQL (Kusto Query Language).

Application Insights is specifically designed for application monitoring. When you add it to your Azure Function, it automatically captures requests, exceptions, and traces, plus any custom events you log.

Azure Workbooks are interactive reports that combine text, KQL queries, and visualizations. They're perfect for security dashboards.

Azure Monitor Alerts let you define rules that trigger when conditions are met. "If more than 10 injections in 5 minutes, email the security team."

How Logs Flow

Understanding the data flow helps when troubleshooting:

Your MCP Request
       │
       ▼
┌──────────────┐     Diagnostic Settings     ┌────────────────────┐
│     APIM     │ ─────────────────────────── │   Log Analytics    │
│   Gateway    │     GatewayLogs             │     Workspace      │
│              │     GatewayLlmLogs          │                    │
│              │     WebSocketConnectionLogs │  ApiManagement...  │
└──────┬───────┘                             │  tables            │
       │                                     └────────────────────┘
       │ Routes to
       ▼
┌──────────────┐     App Insights SDK        ┌────────────────────┐
│   Security   │ ─────────────────────────── │   Application      │
│   Function   │     Custom events +         │   Insights         │
│              │     auto-instrumentation    │                    │
│              │                             │  AppTraces table   │
└──────────────┘                             └────────────────────┘

The 2-5 Minute Delay

Logs don't appear instantly in Log Analytics. Azure buffers and batches them for efficiency, resulting in a 2-5 minute ingestion delay. This is normal! When validating your setup, give it a few minutes before panicking.

Unified Telemetry

Camp 4 uses a single shared Application Insights instance for all services. This enables:

  • Single pane of glass: Query logs from APIM, MCP Server, Functions, and Trail API in one place
  • KQL across services: Write queries that join telemetry from multiple services
  • Transaction Search: Find specific requests by correlation ID and trace them across all services
  • Consistent alerting: Create alerts that span the entire system
┌───────────────────────────────────────────────────────────────────────────┐
│                         Shared Application Insights                       │
│                                                                           │
│    ┌─────────┐     ┌─────────────────┐     ┌──────────────────┐           │
│    │  APIM   │     │  Sherpa MCP     │     │  Trail API       │           │
│    │ Gateway │     │  Server         │     │  (REST)          │           │
│    └─────────┘     └─────────────────┘     └──────────────────┘           │
│                                                                           │
│                    ┌────────────────┐                                     │
│                    │  Security      │                                     │
│                    │  Function      │                                     │
│                    └────────────────┘                                     │
│                                                                           │
│   All services report to the same App Insights for unified queries        │
└───────────────────────────────────────────────────────────────────────────┘

Correlation IDs

Use the x-correlation-id header (based on APIM's RequestId) to trace requests across services in your KQL queries.

Production Sampling Consideration

This workshop uses 100% sampling for complete visibility during learning. In production environments, consider reducing the sampling percentage to optimize costs while maintaining representative telemetry. You can configure this in the Application Insights resource or in the Bicep infrastructure.

Workshop Pattern

Camp 4 follows the explore → understand → actionable pattern for APIM (already configured), and the hidden → visible → actionable pattern for function logging:

  • APIM: Pre-Configured

    APIM diagnostic settings are deployed via Bicep. Gateway logs flow to Log Analytics automatically. Section 1 explores and validates this configuration.

  • Functions: Hidden

    Security function v1 uses basic logging.warning(). Events occur but aren't queryable in Log Analytics. Section 2 fixes this.

  • Actionable

    Create dashboards for monitoring and alerts that notify you when something needs attention. Turn visibility into automated response.

The workshop has 4 sections:

Section Focus Scripts
1. APIM Logging Explore pre-configured diagnostics and validate logs flow section1/1.1-explore.sh → 1.2-verify.sh → 1.3-validate.sh
2. Function Observability Switch from v1 (basic) to v2 (structured logging) section2/2.1-exploit.sh → 2.2-fix.sh → 2.3-validate.sh
3. Dashboard & Alerts Make security actionable section3/3.1-deploy-workbook.sh, 3.2-create-alerts.sh
4. Incident Response Test the complete system section4/4.1-simulate-attack.sh

What You'll Build

  • Structured Logging

    Transform generic log messages into rich, queryable events with custom dimensions like event_type, category, and correlation_id.

  • Security Dashboard

    Visualize attacks, PII redactions, and credential exposures in real-time with Azure Workbooks.

  • Smart Alerting

    Get notified immediately when attack rates spike or credentials are exposed.

  • KQL Queries

    Learn Kusto Query Language to analyze security events and create custom reports.

A Quick KQL Primer

Throughout this workshop, you'll write queries in KQL (Kusto Query Language). If you've never used it, don't worry, it's quite intuitive once you see a few examples.

KQL Basics

KQL queries flow from left to right using the pipe (|) operator, similar to Unix commands:

TableName
| where SomeColumn == "value"      // Filter rows
| project Column1, Column2         // Select columns
| summarize count() by Column1     // Aggregate
| order by count_ desc             // Sort
| limit 10                         // Take top N

Essential Operators

Operator Purpose Example
where Filter rows where ResponseCode >= 400
project Select/rename columns project TimeGenerated, CallerIpAddress
extend Add computed columns extend Duration = DurationMs/1000
summarize Aggregate summarize count() by ToolName
order by Sort order by TimeGenerated desc
limit / take Return N rows limit 20
render Visualize render timechart

Working with Custom Dimensions

The security function logs custom dimensions using Azure Monitor OpenTelemetry. These are stored in Properties.custom_dimensions as a Python dict string (with single quotes). To query them, you need to convert to JSON and parse:

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(
    replace_string(
        replace_string(tostring(Properties.custom_dimensions), "'", "\""),
        "None", "null"
    ))
| extend EventType = tostring(CustomDims.event_type)
| where EventType == "INJECTION_BLOCKED"

Why the Complex Parsing?

Azure Monitor OpenTelemetry for Python stores custom dimensions as a Python dict string, not JSON. This means:

  • Single quotes (') instead of double quotes (")
  • Python None instead of JSON null

The replace_string() calls convert to valid JSON before parse_json() can work.

Pre-filter for Performance

Always use | where Properties has "event_type" before the parsing step. This filters at the storage level and dramatically improves query performance.

Time Filters

KQL has built-in time functions:

| where TimeGenerated > ago(1h)     // Last hour
| where TimeGenerated > ago(7d)     // Last 7 days
| where TimeGenerated between (datetime(2024-01-01) .. datetime(2024-01-31))

You'll get plenty of practice with KQL as we go through the workshop. The KQL Query Reference section at the end has queries you can copy and customize.

Key Log Tables

This workshop focuses on these Azure Monitor log tables for MCP security monitoring:

Log Table APIM Category Key Fields
ApiManagementGatewayLogs GatewayLogs CallerIpAddress, ResponseCode, CorrelationId, Url, Method, ApiId
ApiManagementGatewayLlmLog GatewayLlmLogs PromptTokens, CompletionTokens, ModelName, CorrelationId
AppTraces (App Insights) Message, SeverityLevel, custom dimensions (event_type, correlation_id, injection_type)

MCP Protocol-Level Logging

Azure is developing MCP-specific logging capabilities that will capture tool names, session IDs, and client information at the protocol level. Until generally available, GatewayLogs captures HTTP-level MCP traffic, and AppTraces captures security function events including tool names extracted from JSON-RPC payloads.

Correlation IDs

The CorrelationId field appears across all log tables and is essential for incident response. It allows you to trace a single request from APIM through the security function and back, correlating HTTP logs and application traces.

Prerequisites

Before starting Camp 4, ensure you have:

Azure subscription with Contributor access
Azure CLI installed and logged in (az login)
Azure Developer CLI installed (azd auth login)
Docker installed and running (for Container Apps deployment)
Completed Camp 3: I/O Security (recommended, but not required)

Standalone Lab

While Camp 4 builds on concepts from earlier camps, it's designed to work standalone. The azd up command will deploy everything you need, including the security function from Camp 3.

Full prerequisites guide with installation instructions for all tools.

Getting Started

# Navigate to Camp 4
cd camps/camp4-monitoring

# Deploy infrastructure AND services (~15 minutes)
azd up

Use azd up, not azd provision

The azd provision command only creates Azure infrastructure (APIM, Function App, etc.) but doesn't deploy the actual code. Use azd up which does both:

  • azd provision = Create Azure resources only
  • azd deploy = Deploy code to existing resources
  • azd up = Provision + Deploy (what you want!)

This deploys:

  • Security Function v1 - Basic logging (the "hidden" state) - ACTIVE
  • Security Function v2 - Structured logging with Azure Monitor - deployed but not active
  • Log Analytics Workspace - Central log storage for querying
  • Application Insights - Telemetry collection (shared by all services)
  • APIM Gateway - API Management with diagnostic settings pre-configured
  • Container Apps - MCP server and Trail API backends with OpenTelemetry

Initial State

The deployment creates a ready-to-use observability foundation:

  • APIM diagnostic settings are configured (ApiManagementGatewayLogs flow immediately)
  • APIM's function-app-url named value points to v1 (basic logging)
  • v1 uses logging.warning() which writes to console, not Application Insights

Both function versions are pre-deployed. The workshop scripts switch between them by updating APIM's named value—no redeployment needed!

Once deployment completes, you're ready to start the workshop. Each section follows the "explore the problem → fix it → validate" pattern.

Section 1: API Management Logging

APIM processes all your MCP traffic, and in this workshop, diagnostic settings are pre-configured via Bicep. This section explores what's been configured and validates that logs are flowing.

The Logging Gap: Before & After

Understanding diagnostic settings helps when configuring other Azure resources. Here's what APIM looks like without diagnostic settings vs with them:

WITHOUT: No Diagnostic Settings                WITH: Diagnostics Enabled (Our Setup)
═══════════════════════════════════════        ═══════════════════════════════════════

   MCP Client                                     MCP Client
       │                                              │
       ▼                                              ▼
┌──────────────┐                                ┌──────────────┐
│    APIM      │                                │    APIM      │───────────────────┐
│   Gateway    │                                │   Gateway    │                   │
│              │                                │              │   Diagnostic      │
│  • Routes ✓  │                                │  • Routes ✓  │   Settings        │
│  • Policies ✓│                                │  • Policies ✓│                   │
│  • Logs?     │                                │  • Logs ✓    │                   ▼
└──────┬───────┘                                └──────┬───────┘        ┌─────────────────┐
       │                                               │                │  Log Analytics  │
       ▼                                               ▼                │                 │
┌─────────────┐                                ┌─────────────┐          │ • GatewayLogs   │
│   Backend   │                                │   Backend   │          │ • GatewayLlmLogs│
│   Services  │                                │   Services  │          └─────────────────┘
└─────────────┘                                └─────────────┘                │
                                                                              ▼
Traffic works fine,                            Traffic works AND           KQL Queries
but NO VISIBILITY                              you can QUERY everything    Dashboards
                                                                           Alerts

Why APIM Logging Matters

Azure API Management sits at the front door of your MCP infrastructure. Every request, legitimate or malicious, passes through it. In this workshop, APIM diagnostic settings are pre-configured via Bicep, so you can immediately query logs once azd up completes.

Pre-Configured for Learning

Unlike a default APIM deployment where you'd have no visibility, this workshop configures diagnostic settings automatically during infrastructure deployment. This means:

  • Gateway logs flow to Log Analytics immediately
  • You can start querying traffic right away
  • No manual configuration required

With diagnostic settings enabled, you have full visibility into:

  • Who called your APIs (IP addresses)
  • What MCP tools were invoked
  • How long requests took
  • Which requests failed and why

The Security Guard Analogy

It's like having a security guard who checks IDs and writes down every entry in a log book. The guard does their job, and there's a complete record anyone can review later.

Understanding Diagnostic Settings

Diagnostic Settings are Azure's way of routing telemetry from a resource to a destination. For APIM, you configure:

  • Source: Which log categories to capture (GatewayLogs, GatewayLlmLogs)
  • Destination: Where to send them (Log Analytics workspace)

In this workshop, the Bicep infrastructure configures these automatically. Once deployed, APIM streams logs to your workspace without any manual steps.

1.1 Explore APIM Gateway Logging

Send Traffic and See Logs Flow

Run the script to send traffic through APIM and verify logging:

./scripts/section1/1.1-explore.sh

What this script does:

  1. Sends legitimate MCP requests through APIM
  2. Sends attack requests (SQL injection, path traversal)
  3. Verifies diagnostic settings are configured
  4. Shows sample KQL queries you can run

What you'll see:

Component Status
APIM routes requests Working
Security function blocks attacks Working
Diagnostic settings configured Pre-deployed via Bicep
Logs flowing to Log Analytics Verified

Log Ingestion Delay

Azure Monitor has a 2-5 minute ingestion delay. The first logs from a new deployment may take 5-10 minutes to appear.

1.2 Verify Diagnostic Configuration

Understand What's Configured

Examine the diagnostic settings:

./scripts/section1/1.2-verify.sh

What this does:

Shows you the diagnostic settings deployed via Bicep, including enabled log categories and destination.

ApiManagementGatewayLogs (HTTP level):

Field Description
CallerIpAddress Client IP (for investigations)
ResponseCode HTTP response code
CorrelationId For cross-service tracing
Url, Method Request path and HTTP method
ApiId API identifier for filtering

ApiManagementGatewayLlmLog (AI/LLM gateway):

Field Description
PromptTokens Input token count
CompletionTokens Output token count
ModelName LLM model used
CorrelationId For cross-service tracing

Verify in Azure Portal

You can also view diagnostic settings by navigating to your APIM resource:

APIM → Monitoring → Diagnostic settings → mcp-security-logs

You should see GatewayLogs and GatewayLlmLogs enabled, pointing to your Log Analytics workspace.

1.3 Validate Logs Appear

Wait for Log Ingestion

For new deployments, logs need 2-5 minutes to appear in Log Analytics. If you run this immediately after azd up, you may see "No HTTP logs found yet." Wait a few minutes and try again.

Query APIM Logs

Verify logs are flowing:

./scripts/section1/1.3-validate.sh

HTTP traffic query (ApiManagementGatewayLogs):

ApiManagementGatewayLogs
| where TimeGenerated > ago(1h)
| where ApiId contains "mcp" or ApiId contains "sherpa"
| project TimeGenerated, CallerIpAddress, Method, Url, ResponseCode, ApiId
| order by TimeGenerated desc
| limit 20

Filtering by ApiId vs Url

Using ApiId contains "mcp" is more reliable than Url contains "/mcp/" because ApiId is a structured field set during API import/configuration, while Url parsing can be fragile.

Section 2: Function Observability

APIM logs show HTTP traffic, but the security function's internal operations (what attacks were blocked, what PII was found) are still invisible. This section upgrades from basic logging to structured telemetry.

The Problem with Basic Logging

Most developers start with basic logging—and there's nothing wrong with that for debugging:

logging.warning(f"Injection blocked: {category}")

This produces a log line like:

2024-01-15 14:30:00 WARNING Injection blocked: sql_injection

Simple, readable, and utterly useless for security analysis at scale. Why?

You can't easily query it. Want to count SQL injections vs. shell injections? You'd need to parse the text, hope the format doesn't change, and write fragile regex patterns.

You can't correlate it. Which APIM request triggered this log? There's no correlation ID to link them.

You can't aggregate it. How many attacks per hour? Per tool? Per source IP? Each question requires custom text parsing.

How Correlation IDs Flow Through the System

When a request arrives at APIM, it's assigned a unique RequestId (accessible via context.RequestId in policies). This ID appears as CorrelationId in APIM's gateway logs.

For end-to-end tracing, APIM must explicitly pass this ID to backend services. In our security function calls, the policy includes:

<set-header name="x-correlation-id" exists-action="override">
    <value>@(context.RequestId.ToString())</value>
</set-header>

The security function extracts this header (or generates its own if missing) and includes it in every log event. This enables queries that join APIM gateway logs with function logs:

let id = "YOUR-CORRELATION-ID";
union
    (ApiManagementGatewayLogs | where CorrelationId == id),
    (AppTraces
     | where Properties has "correlation_id"
     | extend CustomDims = parse_json(replace_string(replace_string(
         tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
     | where tostring(CustomDims.correlation_id) == id)
| order by TimeGenerated

Without this explicit header passing, you'd have two disconnected log streams with no way to link them!

Structured Logging: The Solution

Structured logging means emitting events as key-value pairs (dimensions) rather than formatted strings:

log_security_event(
    event_type="INJECTION_BLOCKED",
    injection_type="sql_injection",
    tool_name="search-trails",
    correlation_id="abc-123-xyz"
)

This produces a log entry where each piece of information is a separate, queryable field. Now you can:

// Count attacks by type
AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| where tostring(CustomDims.event_type) == "INJECTION_BLOCKED"
| summarize count() by tostring(CustomDims.injection_type)

// Find all events for a specific request
AppTraces
| where Properties has "correlation_id"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| where tostring(CustomDims.correlation_id) == "abc-123-xyz"

What Are Custom Dimensions?

When you log with Azure Monitor/Application Insights, you can attach custom dimensions—arbitrary key-value pairs that become queryable fields.

In the Properties column of AppTraces, you'll find:

Dimension Example Query Use
event_type INJECTION_BLOCKED Filter security events
injection_type sql_injection Breakdown by attack category
correlation_id abc-123-xyz Cross-service tracing
tool_name search-trails Identify targeted tools
severity WARNING Filter by importance

Think of custom dimensions as adding columns to your log database that you can filter, group, and aggregate.

2.1 See Basic Logging Limitations

Experience Unstructured Logs

Run the script to trigger security events:

./scripts/section2/2.1-exploit.sh

What you'll discover:

The script attempts to query AppTraces in Log Analytics, but with v1's basic logging.warning() calls, the table doesn't even exist! Basic Python logging writes to stdout/console—it doesn't automatically flow to Application Insights as structured, queryable data.

This is the core problem: security events are happening, but they're invisible to your monitoring tools.

No AppTraces table to query
No correlation IDs linking to APIM logs
No way to build dashboards or alerts
Logs exist only in function console output (if you know where to look)

2.2 Deploy Structured Logging

Switch to v2 with Custom Dimensions

Switch APIM to use the pre-deployed v2 function:

./scripts/section2/2.2-fix.sh

No Redeployment Required!

Both function versions were deployed during initial azd up. This script simply updates APIM's named value function-app-url to point to v2. The switch is instant!

What changes:

# v1 (basic): Hard to query
logging.warning(f"Injection blocked: {category}")

# v2 (structured): Rich, queryable events
log_injection_blocked(
    injection_type=result.category,
    reason=result.reason,
    correlation_id=correlation_id,
    tool_name=tool_name
)

Custom dimensions now available:

Dimension Example Value Why It Matters
event_type INJECTION_BLOCKED Filter by event category
injection_type sql_injection Know exactly what was blocked
correlation_id abc-123-xyz Trace across APIM + Function
tool_name search-trails Identify targeted tools

2.3 Validate Structured Logs

Wait for Log Ingestion

The test attacks from 2.2-fix.sh need 2-5 minutes to appear in Log Analytics. If you run this immediately after 2.2, you may see "No structured logs found yet." Wait a few minutes and try again.

Query Security Events

Verify structured events appear:

./scripts/section2/2.3-validate.sh

Count attacks by injection type:

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type),
         InjectionType = tostring(CustomDims.injection_type)
| where EventType == "INJECTION_BLOCKED"
| summarize Count=count() by InjectionType
| order by Count desc

Recent security events with details:

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type),
         InjectionType = tostring(CustomDims.injection_type),
         ToolName = tostring(CustomDims.tool_name),
         CorrelationId = tostring(CustomDims.correlation_id)
| where EventType == "INJECTION_BLOCKED"
| project TimeGenerated, EventType, InjectionType, ToolName, CorrelationId
| order by TimeGenerated desc
| limit 20

Most targeted tools:

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| where tostring(CustomDims.event_type) == "INJECTION_BLOCKED"
| extend ToolName = tostring(CustomDims.tool_name)
| where isnotempty(ToolName)
| summarize AttackCount=count() by ToolName
| order by AttackCount desc

End-to-end correlation (auto-finds latest correlation ID):

This query finds the most recent blocked attack and traces it across both APIM and Function logs:

// Get the most recent correlation ID from a blocked attack
let timeRange = ago(24h);  // Adjust as needed
let recentAttack = AppTraces
| where TimeGenerated > timeRange
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| where tostring(CustomDims.event_type) == "INJECTION_BLOCKED"
| extend CorrelationId = tostring(CustomDims.correlation_id)
| top 1 by TimeGenerated desc
| project CorrelationId;
// Now trace that request across APIM and Function
let correlationId = toscalar(recentAttack);
union
    (ApiManagementGatewayLogs
     | where TimeGenerated > timeRange
     | where CorrelationId == correlationId
     | project TimeGenerated, Source="APIM", CorrelationId,
               Details=strcat("HTTP ", ResponseCode, " from ", CallerIpAddress)),
    (AppTraces
     | where TimeGenerated > timeRange
     | where Properties has "correlation_id"
     | extend CustomDims = parse_json(replace_string(replace_string(
         tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
     | where tostring(CustomDims.correlation_id) == correlationId
     | project TimeGenerated, Source="Function", CorrelationId=tostring(CustomDims.correlation_id),
               Details=strcat(tostring(CustomDims.event_type), ": ", tostring(CustomDims.injection_type)))
| order by TimeGenerated asc

Manual correlation (paste your own ID):

let correlationId = "YOUR-CORRELATION-ID";
union
    (ApiManagementGatewayLogs | where CorrelationId == correlationId),
    (AppTraces
     | where Properties has "correlation_id"
     | extend CustomDims = parse_json(replace_string(replace_string(
         tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
     | where tostring(CustomDims.correlation_id) == correlationId)
| order by TimeGenerated

Section 3: Dashboard & Alerts

Visibility is great, but you can't watch logs 24/7. This section makes security actionable with dashboards and alerts.

From Visible to Actionable

At this point, you've achieved visibility:

APIM logs flow to Log Analytics
Security function emits structured events
You can query anything with KQL

But there's a problem: nobody has time to run KQL queries all day.

The final step in the "hidden → visible → actionable" journey is making security events surface themselves:

  • Dashboards give you at-a-glance status without running queries
  • Alerts notify you when something needs attention, even at 3 AM

Azure Workbooks: Interactive Dashboards

Azure Workbooks are interactive reports built on top of Log Analytics. They combine:

  • Text - Explanations and context
  • KQL Queries - Live data from your logs
  • Visualizations - Charts, graphs, grids
  • Parameters - Interactive filters (time range, environment, etc.)

Unlike static dashboards, Workbooks query live data every time you view them. No ETL pipelines, no data staleness—just direct queries against your logs.

Workbook vs. Dashboard

Azure has both Workbooks and Dashboards. What's the difference?

  • Workbooks: Rich, document-like reports with interactivity. Best for analysis.
  • Dashboards: Pinned tiles from various sources. Best for at-a-glance monitoring.

For security monitoring, Workbooks are usually the better choice because you need the analytical depth.

Azure Monitor Alerts: Automated Notification

Alerts watch your logs and take action when conditions are met. They have three components:

  1. Condition: A KQL query that returns results when something's wrong
  2. Action Group: Who to notify and how (email, SMS, webhook, Logic App)
  3. Severity: How urgent is this? (0-4, where 0 is critical)

For example, our "High Attack Volume" alert:

  • Condition: More than 10 INJECTION_BLOCKED events in 5 minutes
  • Action: Email the security team
  • Severity: 2 (Warning)

Alerts run on a schedule (every 5 minutes by default) and fire when the query returns results.

3.1 Deploy the Dashboard

Create Security Workbook

Deploy the Azure Monitor Workbook:

./scripts/section3/3.1-deploy-workbook.sh

Access the dashboard:

  1. Open the Azure Portal
  2. Navigate to your Log Analytics workspace (log-camp4-xxxxx)
  3. Click Workbooks in the left menu
  4. Select MCP Security Dashboard from the list

If the dashboard appears empty

Do a hard refresh (Cmd+Shift+R or Ctrl+Shift+R) to reload the portal UI. The visualization components sometimes fail to load on first access.

Dashboard panels:

Panel Shows
Request Volume MCP traffic over 24h
Attacks by Type Pie chart of injection categories
Top Targeted Tools Which MCP tools attackers probe
Error Sources IPs generating errors
Recent Events Live feed of security activity

3.2 Create Alert Rules

Dashboards are great when you're looking at them. But security incidents don't wait for business hours. Alert rules watch your logs continuously and notify you when something needs attention.

Understanding Action Groups

Before creating alerts, you need to understand Action Groups, which are Azure's way of defining who gets notified and how.

Think of an Action Group as your incident response contact list:

Action Group: "mcp-security-alerts"
├── Email: security-team@company.com
├── SMS: +1-867-5309 (on-call engineer)
├── Webhook: https://notify.company.com/alerts
└── Azure Function: auto-remediation-function

When an alert fires, it triggers everyone in the Action Group simultaneously. This separation is intentional—you define your notification channels once, then reuse them across multiple alerts.

Start Simple

For this workshop, we'll create an Action Group with just email notifications (or none at all). In production, you'd add SMS for critical alerts, webhooks for Slack/Teams, or even Azure Functions for automated remediation.

Anatomy of an Alert Rule

An alert rule has three parts:

Component What It Does Example
Condition KQL query that returns results when something's wrong "More than 10 injection attacks in 5 minutes"
Action Group Who to notify when condition is met Email the security team
Severity How urgent is this? (0-4) 2 = Warning

The alert service runs your KQL query on a schedule (every 5 minutes by default). If the query returns results, the alert "fires" and notifies your Action Group.

Severity Levels Explained

Azure uses severity levels 0-4. Here's how to think about them:

Severity Name When to Use Example
0 Critical Production down, data breach Credential exposure detected
1 Error Service degraded, security incident Sustained attack volume
2 Warning Needs attention soon Spike in blocked attacks
3 Informational For awareness New attack pattern seen
4 Verbose Debugging only Rarely used for alerts

Alert Fatigue is Real

The biggest mistake teams make is setting thresholds too low. If you get 50 alerts a day, you'll start ignoring them, and miss the real incidents. Start with conservative thresholds (fewer alerts) and tune down as you learn your baseline.

The Alerts We're Creating

Alert Why This Matters
High Attack Volume A sudden spike in blocked attacks often indicates an active attack campaign. One or two blocked injections? Normal probing. Dozens in minutes? Someone's serious.
Credential Exposure Any credential detection is critical, even if redacted, it means sensitive data reached your system. This should wake someone up at 3 AM.
Set Up Automated Notifications

Create alert rules:

./scripts/section3/3.2-create-alerts.sh

The script will prompt for an optional email address. You can skip this and view fired alerts in the Azure Portal instead.

What the script creates:

  1. Action Group (mcp-security-alerts)

    • Short name: MCPSecAlrt (used in SMS notifications)
    • Email receiver (if you provided one)

  2. Alert: High Attack Volume (Severity 2 - Warning)

    • Triggers when >10 attacks detected in 5 minutes
    • Evaluation frequency: Every 5 minutes
    • Use case: Detect active attack campaigns

  3. Alert: Credential Exposure (Severity 1 - Error)

    • Triggers on ANY credential detection
    • Evaluation frequency: Every 5 minutes
    • Use case: Critical security event requiring immediate attention

Verify in Azure Portal:

  1. Navigate to Monitor → Alerts
  2. Click Alert rules to see your configured rules
  3. After an attack simulation, check Alerts for fired alerts

Testing Alerts

Alerts evaluate every 5 minutes, so there's a delay between generating events and seeing alerts fire. After running the attack simulation in Section 4, wait 5-10 minutes before checking for fired alerts.

Section 4: Incident Response

Test the complete observability system with a simulated attack.

Why Practice Incident Response?

Building a monitoring system is one thing. Actually using it under pressure is another.

Security teams practice incident response for the same reason firefighters practice drills: when the real thing happens, you don't want to be figuring things out for the first time.

In this section, you'll:

  1. Simulate a realistic attack - Multiple attack vectors, realistic payloads
  2. Watch your dashboard light up - See the "actionable" part in action
  3. Investigate using correlation IDs - Trace the attack across services
  4. Verify alerts trigger - Confirm your automated notifications work

The Power of Correlation IDs

When investigating an incident, the most valuable tool is the correlation ID. Here's why:

A single user action might touch multiple services:

Client Request → APIM → Security Function → MCP Server → Database

Each service logs independently. Without correlation, you'd have:

  • APIM log: "Request from 203.0.113.42"
  • Function log: "Injection blocked: sql_injection"
  • MCP Server log: "Request failed"

Which function log matches which APIM request? 🤷

With correlation IDs, every service logs the same ID:

APIM:     correlation_id=abc-123, CallerIP=203.0.113.42
Function: correlation_id=abc-123, event_type=INJECTION_BLOCKED
MCP:      correlation_id=abc-123, status=blocked

Now you can instantly reconstruct the full story:

let id = "abc-123";
ApiManagementGatewayLogs | where CorrelationId == id
| union (
    AppTraces
    | where Properties has "correlation_id"
    | extend CustomDims = parse_json(replace_string(replace_string(
        tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
    | where tostring(CustomDims.correlation_id) == id
)
| order by TimeGenerated

4.1 Simulate Multi-Vector Attack

Attack Simulation

Run the attack simulation:

./scripts/section4/4.1-simulate-attack.sh

Attack phases:

  1. Reconnaissance - Probe for available tools
  2. SQL Injection - Multiple payload variations
  3. Path Traversal - Try to access system files
  4. Shell Injection - Command execution attempts
  5. Prompt Injection - AI jailbreak attempts

What to observe:

  • Dashboard shows spike in attack volume
  • "High Attack Volume" alert triggers
  • Email notification (if configured)

Full log correlation query:

The script outputs a correlation ID. Use it to trace the attack across ALL services:

// Correlate attack across APIM and Function logs
let timeRange = ago(1h);
AppTraces
| where TimeGenerated > timeRange
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend CorrelationId = tostring(CustomDims.correlation_id)
| join kind=leftouter (
    ApiManagementGatewayLogs
    | where TimeGenerated > timeRange
    | where ApiId contains "mcp" or ApiId contains "sherpa"
    | project CorrelationId, CallerIpAddress, ResponseCode
) on CorrelationId
| project TimeGenerated, CorrelationId,
    EventType=tostring(CustomDims.event_type),
    InjectionType=tostring(CustomDims.injection_type),
    CallerIpAddress, ResponseCode
| order by TimeGenerated desc
| take 50

KQL Query Reference

This section is your cheat sheet—a collection of queries you'll use regularly for security monitoring. Bookmark this page!

Each query is designed to answer a specific question. Copy them into Log Analytics and modify as needed.

Running KQL Queries

To run these queries:

  1. Go to the Azure Portal → Log Analytics workspace
  2. Click Logs in the left menu
  3. Paste the query and click Run

You can also save frequently-used queries for quick access.

Security Events Summary

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type)
| where EventType in ('INJECTION_BLOCKED', 'PII_REDACTED', 'CREDENTIAL_DETECTED')
| summarize Count=count() by EventType
| render piechart

Attacks by Category

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type)
| where EventType == 'INJECTION_BLOCKED'
| extend Category = tostring(CustomDims.injection_type)
| summarize Count=count() by Category
| order by Count desc

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type)
| where EventType == 'INJECTION_BLOCKED'
| summarize Count=count() by bin(TimeGenerated, 5m)
| render timechart

Most Targeted MCP Tools

AppTraces
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type)
| where EventType == 'INJECTION_BLOCKED'
| extend ToolName = tostring(CustomDims.tool_name)
| where isnotempty(ToolName)
| summarize Count=count() by ToolName
| top 10 by Count desc

Trace a Single Request

// Replace with an actual correlation ID from your logs
let correlation_id = "YOUR-CORRELATION-ID";
AppTraces
| where Properties has "correlation_id"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend CorrelationId = tostring(CustomDims.correlation_id)
| where CorrelationId == correlation_id
| project TimeGenerated, Message, CustomDims
| order by TimeGenerated asc

Full Log Correlation (Incident Response)

Use CorrelationId to trace a request across ALL log tables:

// Cross-service investigation using CorrelationId
let correlationId = "YOUR-CORRELATION-ID";
let timeRange = ago(24h);
// APIM HTTP logs
ApiManagementGatewayLogs
| where TimeGenerated > timeRange
| where CorrelationId == correlationId
| project TimeGenerated, Source="APIM-HTTP", CallerIpAddress, ResponseCode
| union (
    // Security function logs
    AppTraces
    | where TimeGenerated > timeRange
    | where Properties has "correlation_id"
    | extend CustomDims = parse_json(replace_string(replace_string(
        tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
    | where tostring(CustomDims.correlation_id) == correlationId
    | extend EventType = tostring(CustomDims.event_type)
    | project TimeGenerated, Source="Function", EventType, Message
)
| order by TimeGenerated asc

Suspicious Client Analysis

This query identifies IPs with high attack rates:

// Find clients with high attack rates using APIM gateway logs
ApiManagementGatewayLogs
| where TimeGenerated > ago(24h)
| where ApiId contains "mcp" or ApiId contains "sherpa"
| where ResponseCode >= 400
| summarize ErrorCount=count() by CallerIpAddress
| where ErrorCount > 10
| order by ErrorCount desc

MCP Tool Risk Assessment

Identify which tools are most frequently targeted by attackers:

// Which tools are most frequently targeted? (using AppTraces)
AppTraces
| where TimeGenerated > ago(7d)
| where Properties has "event_type"
| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type),
         ToolName = tostring(CustomDims.tool_name)
| where EventType == "INJECTION_BLOCKED" and isnotempty(ToolName)
| summarize AttackAttempts=count() by ToolName
| order by AttackAttempts desc

Cross-Service Queries (Unified Telemetry)

These queries leverage the shared Application Insights instance where all services report telemetry.

Log Analytics Table Names

When querying from Log Analytics workspace, use these table names:

  • AppRequests (not requests)
  • AppDependencies (not dependencies)
  • AppTraces (not traces)

Column names also differ: TimeGenerated (not timestamp), AppRoleName (not cloud_RoleName), Success (not success), DurationMs (not duration).

Service Instrumentation

All services in this workshop have OpenTelemetry instrumentation configured:

  • APIM, funcv1, funcv2: Auto-instrumented, appear in AppRequests
  • trail-api: FastAPI instrumentation, appears in AppRequests when receiving HTTP traffic
  • sherpa-mcp-server: OpenTelemetry configured, appears in AppTraces (MCP uses Streamable HTTP transport, which supports both single JSON responses and SSE streaming for longer operations. APIM proxies these requests to the backend MCP server.)

The queries below union data from both AppRequests and AppTraces to give a complete picture across all services.

Service Health Overview

See request counts and error rates across all instrumented services:

// Request counts and error rates by service (including MCP servers via AppTraces)
let httpServices = AppRequests
| where TimeGenerated > ago(1h)
| summarize
    total = count(),
    failed = countif(Success == false),
    avg_duration_ms = avg(DurationMs)
  by AppRoleName
| extend error_rate = round(failed * 100.0 / total, 2);
let mcpServices = AppTraces
| where TimeGenerated > ago(1h)
| where AppRoleName == "sherpa-mcp-server"
| where Message startswith "get_weather" or Message startswith "check_trail" or Message startswith "get_gear"
| summarize total = count() by AppRoleName
| extend failed = 0, avg_duration_ms = 0.0, error_rate = 0.0;
union httpServices, mcpServices
| project AppRoleName, total, failed, error_rate, avg_duration_ms
| order by total desc

Security Function Performance

Analyze the security function's input-check and sanitize-output endpoints:

// Security function endpoint performance
AppRequests
| where AppRoleName contains "func"
| where TimeGenerated > ago(1h)
| summarize
    avg_duration = avg(DurationMs),
    p95_duration = percentile(DurationMs, 95),
    success_rate = round(countif(Success == true) * 100.0 / count(), 2),
    request_count = count()
  by Name
| order by request_count desc

MCP Tool Performance (Custom Spans)

Track individual MCP tool execution from sherpa-mcp-server logs:

// MCP tool invocations from sherpa-mcp-server
AppTraces
| where TimeGenerated > ago(24h)
| where AppRoleName == "sherpa-mcp-server"
| where Message startswith "get_weather" or Message startswith "check_trail" or Message startswith "get_gear"
| extend tool = case(
    Message startswith "get_weather", "get_weather",
    Message startswith "check_trail", "check_trail_conditions",
    Message startswith "get_gear", "get_gear_recommendations",
    "unknown")
| extend location = extract("location=([^,]+)", 1, Message)
| summarize call_count = count() by tool
| order by call_count desc

MCP Tool Usage Patterns

See which parameters are being passed to MCP tools:

// MCP tool parameter analysis from sherpa-mcp-server
AppTraces
| where TimeGenerated > ago(24h)
| where AppRoleName == "sherpa-mcp-server"
| where Message startswith "get_weather" or Message startswith "check_trail" or Message startswith "get_gear"
| extend tool = case(
    Message startswith "get_weather", "get_weather",
    Message startswith "check_trail", "check_trail_conditions",
    Message startswith "get_gear", "get_gear_recommendations",
    "unknown")
| extend location = extract("location=([^\"\\)]+)", 1, Message),
         trail_id = extract("trail_id=([^\"\\)]+)", 1, Message),
         conditions = extract("conditions=([^\"\\)]+)", 1, Message)
| project TimeGenerated, tool, location, trail_id, conditions
| where isnotempty(location) or isnotempty(trail_id) or isnotempty(conditions)

Slowest Requests Across All Services

Find performance bottlenecks:

// Top 20 slowest requests across all services
AppRequests
| where TimeGenerated > ago(1h)
| where Success == true
| top 20 by DurationMs desc
| project
    TimeGenerated,
    service = AppRoleName,
    Name,
    duration_ms = round(DurationMs, 2),
    ResultCode

All Services Activity Summary

Compare activity across all services (HTTP requests + MCP tool calls):

// Activity summary across all services
let httpActivity = AppRequests
| where TimeGenerated > ago(1h)
| summarize
    request_count = count(),
    avg_duration_ms = round(avg(DurationMs), 2)
  by AppRoleName;
let mcpActivity = AppTraces
| where TimeGenerated > ago(1h)
| where AppRoleName == "sherpa-mcp-server"
| where Message startswith "get_weather" or Message startswith "check_trail" or Message startswith "get_gear"
| summarize request_count = count() by AppRoleName
| extend avg_duration_ms = 0.0;  // Duration not tracked in current logging
union httpActivity, mcpActivity
| order by request_count desc

Architecture Deep Dive

Let's look at how all the pieces fit together. Understanding this architecture helps when troubleshooting and when designing your own monitoring solutions.

Data Flow: From Request to Dashboard

┌─────────────────────────────────────────────────────────────────┐
│                         MCP Client                              │
└───────────────────────────────┬─────────────────────────────────┘
                                │ HTTPS Request
                                ▼
┌─────────────────────────────────────────────────────────────────┐
│                     API Management (APIM)                       │
│   • Receives all MCP traffic                                    │
│   • Applies policies (auth, rate limiting)                      │
│   • Generates CorrelationId for tracing                         │
│   • Routes to security function                                 │
│                                                                 │
│   Diagnostic Settings → Log Analytics                           │
│   └── GatewayLogs (HTTP details)                                │
│   └── GatewayLlmLogs (LLM usage)                                │
│   └── WebSocketConnectionLogs (WebSocket events)                │
└───────────────────────────────┬─────────────────────────────────┘
                                │
                                ▼
┌─────────────────────────────────────────────────────────────────┐
│                    Security Function                            │
│   • Receives forwarded request + CorrelationId                  │
│   • Checks for injection patterns                               │
│   • Scans for PII/credentials in responses                      │
│   • Logs structured events with custom dimensions               │
│                                                                 │
│   Application Insights SDK → AppTraces table                    │
│   └── event_type, injection_type, correlation_id                │
└─────────────────────────────────────────────────────────────────┘

The Security Event Types

The security function emits five distinct event types, each serving a specific purpose:

Event Type When Emitted Severity What to Do
INJECTION_BLOCKED Attack pattern detected in input WARNING Investigate source, consider blocking IP
PII_REDACTED Personal data found and masked in output INFO Normal operation, audit trail
CREDENTIAL_DETECTED API keys/tokens found in output ERROR Immediate investigation, possible breach
INPUT_CHECK_PASSED Request passed all security checks DEBUG Normal operation
SECURITY_ERROR Security function itself failed ERROR Check function health, review logs

Log Table Relationships

Here's how the tables connect via CorrelationId:

ApiManagementGatewayLogs                       AppTraces
┌────────────────────────┐                     ┌─────────────────────────┐
│ CorrelationId: abc-123 │─────────────────────│ correlation_id: abc-123 │
│ CallerIpAddress: ...   │                     │ event_type: INJECTION.. │
│ ResponseCode: 200      │                     │ injection_type: sql_... │
│ ApiId: sherpa-mcp      │                     │ tool_name: search-trails│
│ Method: POST           │                     │ category: sql_injection │
└────────────────────────┘                     └─────────────────────────┘

This is why correlation IDs are so powerful: one ID links together HTTP details and security events.

Outbound Policy Considerations

APIM outbound policies can inspect and modify responses, but there's an important limitation with streaming responses:

Response Type context.Response.Body.As<string>() Outbound Policy Safe?
Single JSON ✅ Returns complete body ✅ Yes
SSE Stream ⚠️ May timeout or return partial data ⚠️ Unreliable

Why the workshop's outbound sanitization works:

The sherpa-mcp-server returns single JSON responses for its simple tools. The connection closes after the complete response, so APIM can buffer and inspect the body.

<!-- This works because sherpa-mcp-server returns complete JSON responses -->
<set-body>@(context.Response.Body.As<string>(preserveContent: true))</set-body>

If Your MCP Server Returns SSE Streams

If you modify the MCP server to return SSE streams (for long-running operations or progress updates), the outbound policy will:

  • Timeout waiting for the stream to complete
  • Get partial data if the stream takes longer than the policy timeout
  • Block streaming if buffer-response="true" is set

For streaming MCP servers, move security validation to:

  1. Inbound policies (validate input before forwarding)
  2. The MCP server itself (sanitize before streaming)

Troubleshooting

Things don't always work the first time. Here are the most common issues and how to fix them.

My KQL queries return no results

Don't panic! This is the #1 issue people hit. Check these things in order:

  1. Wait 2-5 minutes. Logs don't appear instantly. If you just enabled diagnostics or deployed the function, grab a coffee and try again.

  2. Check your time range. The default in Log Analytics might be "Last 24 hours", if you just deployed, try "Last 1 hour" or "Last 30 minutes".

  3. Verify diagnostic settings exist:

    az monitor diagnostic-settings list \
  --resource "/subscriptions/.../providers/Microsoft.ApiManagement/service/YOUR-APIM" \
  --query "[].name"

  4. Verify Application Insights is connected:

    az functionapp config appsettings list \
  --name $FUNCTION_APP_NAME \
  --resource-group $AZURE_RESOURCE_GROUP \
  --query "[?name=='APPLICATIONINSIGHTS_CONNECTION_STRING']"

  5. Generate some events! Run the exploit scripts to create log entries, then wait a few minutes.

The dashboard shows 'No data'

Workbooks need data to display. If panels are empty:

  1. Adjust the time range at the top of the workbook to a wider window (try "Last 7 days")

  2. Generate events by running:

    ./scripts/section4/4.1-simulate-attack.sh

  3. Wait for ingestion (2-5 minutes), then refresh the workbook

  4. Check the workspace connection - Make sure the workbook is querying the right Log Analytics workspace

Alerts aren't firing even though I see events

Alerts run on a schedule, not in real-time:

  1. Alert evaluation interval: Default is every 5 minutes. Wait at least 10 minutes after generating events.

  2. Check thresholds: The "High Attack Volume" alert requires >10 attacks in 5 minutes. Did you generate enough events?

  3. Verify the alert is enabled:

  4. Azure Portal → Monitor → Alerts → Alert rules

  5. Check that your rules show "Enabled"

  6. Check action group: Even if the alert fires, notifications need a properly configured action group with valid email/webhook.

Properties.event_type returns nothing but I see the data

Custom dimensions in OpenTelemetry are stored differently than expected.

The Azure Monitor OpenTelemetry SDK for Python stores custom dimensions in Properties.custom_dimensions as a Python dict string (with single quotes), not as direct JSON properties.

Wrong approach (won't work):

| extend EventType = tostring(Properties.event_type)  // ✗ Returns empty
| where Properties.event_type == "INJECTION_BLOCKED"  // ✗ No matches

Correct approach (parse the custom_dimensions):

| extend CustomDims = parse_json(replace_string(replace_string(
    tostring(Properties.custom_dimensions), "'", "\""), "None", "null"))
| extend EventType = tostring(CustomDims.event_type)  // :material-check: Works
| where EventType == "INJECTION_BLOCKED"  // :material-check: Matches

Check what's actually in Properties:

AppTraces
| where Properties has "event_type"
| take 1
| project Properties

You'll see something like:

{"custom_dimensions": "{'event_type': 'INJECTION_BLOCKED', ...}"}

Note the single quotes inside custom_dimensions - that's a Python dict string, not JSON!

I'm seeing 'Request rate is large' errors

You might be hitting rate limits. This happens if you:

  • Run attack simulations too fast
  • Have multiple people using the same deployment

Solution: Wait a few minutes, or add delays between requests in your scripts.

Cleanup

# Remove all Azure resources
azd down --force --purge

# Clean up Entra ID apps (optional - ignore errors if already deleted)
az ad app delete --id $(azd env get-value MCP_APP_CLIENT_ID)
az ad app delete --id $(azd env get-value APIM_CLIENT_APP_ID)

Congratulations!

You've completed Camp 4: Monitoring & Telemetry and reached Observation Peak! One more climb to go. The Summit awaits!

Your Journey: Hidden → Visible → Actionable

Think back to where you started:

Before After
APIM routed traffic silently Every request logged with caller IP, timing, correlation
Function logged basic warnings Structured events with custom dimensions for rich querying
No way to see attack patterns Real-time dashboard showing security posture
Manual log checking Automated alerts notify you of threats

You've transformed your MCP infrastructure from a "black box" into a fully observable system.

What You've Accomplished

Enabled APIM diagnostics with GatewayLogs, GatewayLlmLogs, and WebSocketConnectionLogs
Implemented structured logging with correlation IDs and custom dimensions
Built a security dashboard using Azure Workbooks
Configured alert rules for attack detection
Learned KQL for security investigations
Practiced incident response with cross-service log correlation

The Hidden → Visible → Actionable Pattern

This pattern applies beyond just monitoring:

  • Hidden problems → Use diagnostics, logging, tracing to make them visible
  • Visible data → Use dashboards, alerts, automation to make it actionable

Whenever you deploy something new, ask yourself: "If this breaks at 3 AM, how will I know? How will I investigate?"

Skills You've Gained

Skill What You Can Now Do
Azure Monitor Configure diagnostic settings, use Log Analytics
KQL Write queries to investigate security events
Structured Logging Design log events that are queryable at scale
Dashboarding Build Workbooks for security visualization
Alerting Create rules that notify on security thresholds
Incident Response Trace requests across services using correlation IDs

🏔️ Almost at the Summit!

You've completed all four skill-building camps:

Camp What You Secured
Base Camp Understanding MCP vulnerabilities
Camp 1: Identity OAuth 2.0 + Entra ID authentication
Camp 2: Gateway APIM protection + rate limiting
Camp 3: I/O Security Input validation + output sanitization
Camp 4: Monitoring Full observability + alerting

Your MCP servers are now authenticated, protected, validated, and observable.

What's Next: The Summit

You've learned all the individual security skills. Now it's time to put them all together!

The Summit is where you'll deploy the complete secure MCP infrastructure and test it with realistic red team / blue team exercises.

One more climb to go! 🏔️

← Camp 3: I/O Security | The Summit →
